5pcs 22PIN Male SATA Connector 7+15P Sinking Plate SSD Socket
5pcs 22PIN Male SATA Connector 7+15P Sinking Plate SSD Socket
5-Pack 22PIN Male SATA Interface Connector – Sinking Plate SSD Drive Socket
Upgrade or repair your storage drive connections with these precision-engineered 22-pin male SATA interface sockets. Featuring a sinking plate (patch-type) design with a combined 7-pin data + 15-pin power (7+15P) configuration, these connectors are ideal for PCB-level SSD builds, motherboard repairs, DIY electronics projects, and industrial assembly work. Made in Mainland China.
Key Features
- 22-Pin SATA Interface: Standard 7+15P combined connector — compatible with most 2.5" SSD and HDD SATA applications.
- Sinking Plate / SMT Patch Design: Low-profile through-board mounting keeps your PCB layout clean and compact.
- Durable Construction: Built from high-quality plastic housing and metal contacts for reliable, long-lasting conductivity.
- Pack of 5: Great value — keep spares on hand for repairs, prototyping, or batch PCB production.
- Brand New & High Quality: Each connector is manufactured to tight tolerances for a secure, stable fit.
Specifications
| Interface Type | SATA 22-Pin (7+15P) |
| Gender | Male |
| Mounting Type | Sinking Plate / SMT Patch |
| Material | Plastic + Metal |
| Quantity | 5 Pieces |
| Country of Origin | Made in Mainland China |
What's in the Box?
- 5 × 22PIN Male SATA Sinking Plate Connector (7+15P Patch Type)
Important Notes
- Product images are for reference only; please refer to the written specifications for exact dimensions.
- Allow for ±5–10 mm variance due to manual measurement.
- Actual color may vary slightly from images due to monitor settings and lighting conditions.
Related Products You May Like
- 1PC Large Capacity Battery Storage Organizer Box – Vintage Beer Crate Style, Holds 30 AAA Batteries
- 1PC Mobile Data Cable Storage Box – Portable Winding Earphone & Charger Organizer with Lid
Learn more: ENERGY STAR product efficiency guidance
Frequently Asked Questions
Q: What devices are these 22PIN SATA connectors compatible with?
A: These 22-pin SATA connectors (7-pin data + 15-pin power) are compatible with standard 2.5" SATA SSDs and HDDs. They are primarily designed for PCB-level integration, motherboard repair, and custom electronics builds that use a standard SATA interface.
Q: What does "sinking plate" or "patch type" mounting mean?
A: A sinking plate (also called SMT patch or through-board) design means the connector mounts flush or slightly recessed into the PCB surface, resulting in a lower profile compared to standard upright connectors. This makes them ideal for compact or slim-profile SSD enclosures and custom motherboard layouts.
Q: Are these connectors suitable for DIY and prototyping projects?
A: Absolutely. The 5-piece pack is perfect for DIY electronics enthusiasts, PCB prototypers, and repair technicians who need reliable SATA connectors in small quantities. The durable plastic-and-metal construction ensures a dependable connection in both test and production environments.
Production & Packaging Notice
To maintain high stock availability and fast shipping times, our items are sourced from multiple verified manufacturing facilities. While the core quality, materials, and product specifications remain identical, you may notice slight variations in the packaging design, manufacturing origin, or the wording of the printed instructions.
